Pocket HD™
Introduction
Pocket HD™
188080

The new NEXIQ Pocket Heavy Duty handheld scan tool provides immediate access to critical diagnostic information. Pocket HD comes loaded with both Heavy Duty Standard (HDS) and Light and Medium Truck 2016 (LMT). The ability to run special tests not included.

This tool is both versatile and reliable. With a larger display and easy-to-use, user-friendly features, the Pocket HD puts essential diagnostic information at your fingertips. Whether you are responsible for maintaining a large fleet or just a truck or two, this handy tool makes gathering the diagnostic information you need easy.

Specifications
Pocket HD™ Can Be Used as a Triage Tool and Is Ideal for the Following
Aftermarket diesel technicians
Fleet technicians
OEM Dealers (PM Techs)
Owner/Operators
Maintenance facilities (non-repair)
Comes Pre-loaded with the Following Software Modules
Light and Medium Truck (LMT) 2016 (does not included special tests)
Heavy Duty Standard and OBD II Suite (supports J1708 and J1939 communication)
Comes with the Following
9-pin Deutsch adapter
16-pin J1962 (ODB II) adapter
26-pin data cable
Carrying case
USB power adapter and USB Type C cable
Capabilities
— View and clear current and historic faults
— Monitor all vehicle data
— Check engine speed and load, pressures, temperatures, and more
— Display trip data
— Collect and store data from multiple vehicles
Note: PLC converter required for trailer brake PLC systems (PN 604020, available separately)
Two Additional Software Titles Available Separately
PN 917022: HD/LMT DPF Regen
Provides coverage for the following manufacturers:
– – PACCAR
– – Cummins
– – Volvo/Mack
– – Hino
– – NAVISTAR MaxxForce
– – DDEC 6, 10, 13
– – Dodge/RAM Diesel Engines
– – Ford Diesel Engines
– – GM Diesel Engines
– – Isuzu Diesel Engines
PN 918021: ABS Software Suite
Includes the following three suites:
Bendix ABS Suite
– – Includes Bendix EC-80, TABS-6 Advanced, Tire Pressure Monitoring System (TPMS), EC-60, TABS-6, EC-30, and EC-17
Meritor WABCO Suite
– – Includes Air D&E series tractor and trailer, Hydraulic (Tractor), and On-Guard™ Collision Mitigation System (CMS)
Trailer ABS Suite
– – Includes Wabash National MBS-1P and MBS-2, Eaton GEN4 and GEN5, and Haldex PLC, PLC Plus, and PLC Select
Accessories

ABS Software Suite

918021

Heavy Duty ABS Application Suite

6-Pin Deutsch Adapter

494024

Standard 6-pin Deutsch adapter.

Universal J560 PLC Adapter

604020

Supports PLC Communication.

Complete ABS Kit

798021

Coverage for a wide range of brake applications.
